Strega Smart Valve

device 46
Strega smart valve 3 Strega smart valve 2

Description

The STREGA time-controlled shut-off valve is a battery-operated wireless valve with embedded LoRaWAN® technology. With its ultra-low-power consumption, the Smart-Valve can be triggered for remote OPEN/CLOSE operations. The valve is working on batteries during 10+ years (Class A) or limitless on external power supply (Class C). It communicates on extreme long distances with exceptional deep indoor signal penetration.
Contact Us
Key Features
Use Cases
Downloads
Key Features
  • LoRaWAN wireless shut-off valve
  • Automatic schedules: programmable OPEN/CLOSE sequences
  • Extreme range signal propagation
  • Battery operated with ultra-low consumption - 10-15 years autonomy
  • Lorawan Class A and Class C
  • Time-controlled automatic operations
  • Pipe size from ON 10 to DN80 (3/8" to 3")
  • Fraud resistant with tamper
  • Digital and analog sensors: 2 x digital inputs, one 0-10VDC analog measurement, temperature and hygrometry sensor, leak detection
  • Industrial grade (PN25, IP67, fluid up to 140°C/284°F, ... ), cold and hot fluids
  • Exceptional signal penetration through obstacles
  • Free of charge Android and iOS App

Leak Detection

No image

Monitor pipe pressure and water flow through water network for early detection of irregular readings that may indicate a leak

Pressure Sensing

No image

Monitor changes in flow and pressure through water infrastructure to prevent service disruptions and safety risks

Building monitoring

No image

Connected to an alarm contact, pressure or humidity sensor for instance, the valve can be turned off at a main line to stop leaks before major damage is done

Use the download button below to download the following file:

  • Strega Smart Valve Data sheet
Unable to download file, the specified file does not exist.
