Decentlab DL-MBX Ultrasonic
Description
The Decentlab DL-MBX Ultrasonic Sensor enables remote monitoring of water level, fill level of tanks and silos, fill level of waste containers, presence of objects or snow level. It measures the distance between the sensor head and the target (rangefinder). The measurement principle is based on ultrasonic waves which are transmitted by the sensor and reflected back from nearby objects. Using the time of flight of the sound waves and the speed of sound (temperature compensated), the sensor computes the traveling distance and thus the distance to the object.
Key Features
Use Cases
Downloads
Key Features
- LoRaWAN-enabled non-contact distance sensor (rangefinder)
- Range: 5 m / 10 m; resolution: 1 mm.
- Compatible with LoRaWAN. networks of any provider
- Place and measure: no setup required
- Configurable via command line interface and downlink command interface
- Unattended real-time monitoring for several years without replacing batteries
- Robust polycarbonate enclosure: weatherproof, impact-, UV-resistant (IP67)
- Standard alkaline (C-type) batteries.
- CE compliant, Radio Equipment Directive (RED) 2014/53/EU
Tanks and silos
Fill level monitoring in grain, fertilizer or pellets silos and water tanks
Flood Monitoring
No image
Waste Management
Detect the volume of waste in each container to optimise waste collection scheduling
Sewer Systems
Real-time monitoring of water levels to improve the safety, reliability and efficiency of sewer infrastructure
Use the download button below to download the 2 following files:
- Decentlab DL MBX Data sheet
- NNNCo Decentlab Ultrasonic product sheet
